Rafter Tray

Product Code: KP964800 KP964900

Rafters Trays, also known as Rafter Ventilators, prevent insulation material from blocking the ventilation path, whilst ventilating the roof space and acting as an integral insect screen. Ideal for open eaves situations.

  • Protects against birds and insects, whilst allowing airflow into the roof space
  • Quick and easy to install
  • Lightweight and durable
  • Klober Rafter Tray 450mm

    More Information

    Rafter Trays, also known as Rafter Ventilators, are a simple but effective way of preventing loft insulation from being pushed up to the underside of the roofing underlay and will maintain a clear ventilation path into the roof void from the eaves. Whilst also acting as an integral insect screen.

    Specifications

    Technical Data
    Colour
    Black
    Material
    High-impact styrene
    Eaves Ventilation area
    10000 mm2/m
    Dimensions and Weights
    Width
    430mm
    Length
    450mm
    Depth
    18mm
    Coverage
    4.5m
    Packaging
    Number of Pieces per Carton/Pack
    100
    Number of Carton/Pack on Pallet
    30
    Number of Pieces per Pallet
    3000
    Weight per Pallet
    330 kg
    Technical Data
    Colour
    Black
    Material
    High-impact styrene
    Eaves Ventilation area
    10000 mm2/m
    Dimensions and Weights
    Width
    430mm
    Length
    620mm
    Depth
    18mm
    Coverage
    6m
    Packaging
    Number of Pieces per Carton/Pack
    100
    Number of Carton/Pack on Pallet
    20
    Number of Pieces per Pallet
    2000
    Weight per Pallet
    300 kg

    Installation

    • Trays are nailed or stapled to rafters ensuring the direction arrow is pointed down towards the eaves
    • In open rafter situations trays should be fitted 30 - 35mm clear of the front of the brickwork to ensure adequate ventilation
    • Trays should be fitted between every rafter space

    Area of application

    • Suitable for roofs with a pitch over 15°
    • Closed and open rafters at 450mm and 600mm rafter centres

    Standards and Certifications

    10 Year Guarantee
    10 Year Guarantee
    BS5250 - Ventilation and Management of Moisture
